Specs
Display |
None
|
Channels of I/O |
Analog:
2 Inputs / 4 Outputs |
Maximum Sampling Rate |
96 kHz / 24-Bit
|
Number of Microphone Preamps |
2 Preamps
|
Built-In Microphone |
Yes
|
Input Level Adjustment |
2 x Knob
|
Pad |
None
|
Gain/Trim Range |
Mic/Hi-Z Inputs:
45 dB |
High-Pass Filter |
None
|
Analog Audio I/O |
2 x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Hi-Z Input
2 x RCA Coaxial Unbalanced Line Output 1 x 1/8" / 3.5 mm TRS Unbalanced Aux Input 1 x 1/8" / 3.5 mm TS Unbalanced Mic Input (Front Panel) 1 x 1/8" / 3.5 mm TRRS Unbalanced Headphone/Headset In/Out (Front Panel) 1 x 1/4" TRS Unbalanced Headphone Output (Front Panel) |
Phantom Power |
48 V, Selectable On/Off (Selectable on Individual Inputs)
|
Digital Audio I/O |
None
|
Host Connection |
1 x USB-B
|
Host Connection Protocol |
USB 2.0
|
USB (Non-Host) |
1 x Micro-USB (Power Input)
|
Sync I/O |
None
|
Network I/O |
None
|
MIDI I/O |
None
|
Frequency Response |
Line Outputs:
20 Hz to 20 kHz +0/-1 dB (at 44.1/48 kHz) 20 Hz to 40 kHz +0/-1 dB (at 88.2/96 kHz) 1/4" Headphone Outputs: 20 Hz to 20 kHz +0/-3 dB (at 44.1/48 kHz) 20 Hz to 40 kHz +0/-3 dB (at 88.2/96 kHz) |
Maximum Input Level |
+7.7 dBV
|
Maximum Output Level |
Line Outputs:
+6 dBV |
Headphone Output Power |
15 mW per Channel into 32 Ohms
|
Impedance |
XLR Mic Inputs:
2.4 Kilohms 1/8" / 3.5 mm Mic Inputs: ≥ 5 Kilohms 1/8" / 3.5 mm Aux Inputs: ≥ 5 Kilohms Line Outputs: ≥ 200 Ohms Hi-Z Inputs: ≥ 1 Megohms |
SNR |
Mic Inputs:
100 dB |
THD |
Mic Inputs:
≤ 0.005% (1 kHz) |
Crosstalk |
Mic Inputs:
95 dB (1 kHz) |
EIN |
Mic Inputs:
< -120 dB (150-Ohm Source) |
OS Compatibility |
Windows 7
Windows 8.1 Windows 10 macOS 10.9 or Later iOS 7 or Later iPadOS *As of June, 2022: Check with manufacturer for the most up-to-date compatibility |
Included Software |
None
|
Processor Requirement |
2 GHz
|
RAM Requirements |
2 GB
|
Mobile Device Compatibility |
iPhone
iPad |
Required Hardware |
Available USB 2.0 Port
|
Internet Connection |
Required for Software/Driver Download
|
Power Requirements |
DC Input or USB Bus Power
|
AC/DC Power Adapter |
5 VDC (Not Included)
|
Power Consumption |
1.5 W
|
Anti-Theft Features |
Kensington Security Slot
|
Operating Temperature |
41 to 95°F / 5 to 35°C
|
Dimensions |
7.9 x 5.1 x 1.6" / 20 x 13 x 4 cm
|
Weight |
1.1 lb / 0.5 kg
|
