Let's say you bought gorgeous new M!KA microphone arms for the studio. And you got the ones with the tally lights. So how exactly do you light those up anyway? With the Mic Tally Gizmo, of course!
The 5-pin XLR topside carries the microphone audio and the signal voltage for the tally light. The microphone signal is passed through to a 3-pin XLR connector on the bottom. Dual logic inputs drive the tally either red or white. Red is usually the color for on-air. White can be used for an alternate signal. Ready light, talkback indicator, phone ringer, pizza delivery. You'll come up with a bright idea.
Specs
Mic Arm Input | 5-pin XLR female jack |
Mic Thru | 3-pin XLR male jack |
Logic Ports | 3.5mm TRSS jack |
Power | 15VDC input |
Power Input (Adapter) | 115VAC or 230VAC, 50-60Hz |
Power Output (Adapter) | 15VDC, 200mA, 3.0W |
Tally Output | 12VDC, 80mA |
Operating Temperature | 0º to 40º C (32º to 104º F) |
Storage Temperature | -20º to 45º C (-4º to 113º F) |
Relative Humidity | 0% to 90% non-condensing |
Width x depth x height (Gizmo) | 2.25 x 2.25 x 3.25 in. |
Weight (Gizmo and Adapter) | 1.0 pound, 0.46 kilograms |
