AUDIOSCIENCE ASI1494 EIGHT 1/4 INCH TRS ( TIP RING SLEEVE ) INPUT MODULE

The ASI1494 8 ¼” TRS Connector provides 8 standard ¼ inch TRS (Tip, Ring, Sleeve) balanced jacks. Connections for the ASI1461 Mic/Line In Module are shown in the diagram to the left.
