BROADCAST TOOLS AES-DA-2X4/1X8EIGHT OUTPUT AES/EBU DISTRIBUTION SYSTEM WITH RJ45 I/O

BROADCAST TOOLS AES-DA-2X4/1X8EIGHT OUTPUT AES/EBU DISTRIBUTION SYSTEM WITH RJ45 I/O

BROADCAST TOOLS COA-9-XDS/MAX CONNECT-O-ADAPTER 9—DB-9 TO TERMINAL BLOCK ADAPTER FOR: XDS, WEGENER IPUMPS, MAX, AND NON-OPTION B SFX SATELLITE RECEIVERS. SANALOG ONLY.

BROADCAST TOOLS COA-9-XDS/MAX CONNECT-O-ADAPTER 9—DB-9 TO TERMINAL BLOCK ADAPTER FOR: XDS, WEGENER IPUMPS, MAX, AND NON-OPTION B SFX SATELLITE RECEIVERS. SANALOG ONLY.

BROADCAST TOOLS AES-DA-1X6 SIX OUTPUT AES/EBU DISTRIBUTION SYSTEM WITH XLRS. DUAL POWER SUPPLY INPUTS

Broadcast Tools
SKU
BT-AES-DA-1X6
MFR#
AES-DA-1X6
was $489.00 Special Price $439.00
Availability: Out of stock

BROADCAST TOOLS AES-DA-1X6 SIX OUTPUT AES/EBU DISTRIBUTION SYSTEM WITH XLRS. DUAL POWER SUPPLY INPUTS

Be the first to review this product
Add to Wish List:

SPECIAL SHIPPING RATES

On orders over $1000

WHOLESALING PRICING

Ask us how to become a Wholesaler

SECURED PAYMENT

Guaranteed safe payment options

Six XLR Output, One Input AES/EBU Distribution Amplifier, Dual Power Input Jacks, Front Panel LED Indicators and SPDT Alarm Relay, Designed to Distribute Audio Signals Reliably, Ideal for Broadcast Studios, Live Sound Systems, and Recording Studios. The AES DA 1×6 is a highly efficient, six XLR output, one-input AES/EBU distribution amplifier, perfect for distributing AES/EBU signals or word clock in professional audio environments. Its robust design and dual power input jacks, allowing for redundant power with an optional second power supply, make it a reliable choice for critical audio applications.

Your Rating

Features

  • 1×6 AES/EBU Distribution
  • Jumper Selectable AES Input Termination: 110-ohm, 75-ohm, Open
  • Dual Power Input Jacks for Optional Redundant Power
  • Input Signal Monitoring with LED Indicators and SPDT Alarm Relay Output
  • XLR Inputs and Outputs with Standard Pinout
  • Signal Bypass on Loss of Power, Routing Input 1 to Output 1
  • Fully RFI Proofed Design
  • Surge Protected Internal Power Supply
  • 9 VDC Desktop Universal Switching Power Supply Included
  • Compatibility with RA-1 Rack Shelf for Mounting up to Two Units
  • Desktop and Wall Mounting Options
