Specs
Form Factor |
Desktop
|
Number of Tracks |
6
|
Maximum Sampling Rate |
44.1 kHz / 16-Bit
|
Built-In Microphone |
2 x Omnidirectional Condenser
|
Analog Audio I/O |
1 x 1/8" / 3.5 mm TRS Headphone Output
1 x 1/8" / 3.5 mm TRS Stereo/Line Output 2 x 1/4" TS Unbalanced Line Input |
USB (Non-Host) |
1 x Mini-USB (USB 2.0, External Storage)
|
Frequency Response |
20 Hz to 20 kHz +1/-3 dB
|
Maximum Input Level |
Line Inputs:
+6 dBV |
Maximum Output Level |
Line Outputs:
0 dBV |
Headphone Output Power |
15 mW per Channel into 32 Ohms (Max, 0.1% THD)
|
Impedance |
Mic/Line Inputs:
≥ 10 Kilohms Hi-Z Inputs: 1 Megohm |
SNR |
> 81 dB
|
THD |
< 0.05%
|
Supported Media |
SD Card
|
Memory Card Slot |
1 x SDHC
|
Supported Media Capacity |
SD/SDHC:
32 GB Minimum |
File System Support |
Tascam (MTR), FAT32
|
OS Compatibility |
Windows XP
Windows Vista Windows 7 macOS 10.2 or Later *As of November, 2021: Check with manufacturer for the most up-to-date compatibility |
Power Requirements |
Battery, AC/DC Power Adapter (Not Included)
|
Power Consumption |
1 W (Maximum)
|
Battery Type |
4 x AA
|
Approximate Battery Life |
8 Hours (Alkaline, Recording, Line Input)
9 Hours (NiMH, Recording, Line Input) 8.5 Hours (Alkaline, Playback, with Headphones) 9.5 Hours (NiMH, Playback, with Headphones) |
Operating Temperature |
41 to 95°F / 5 to 35°C
|
Dimensions |
6.1 x 1.63 x 4.2" / 155 x 41.5 x 107 mm
|
Weight |
12.7 oz / 360.0 g
|
