Specs
Format |
44.1 kHz / 48 kHz, 16-Bit / 24-Bit
|
Connector |
4-Pin USB b-Type
|
Transfer Rate |
USB 2.0 High-Speed (480 Mbps)
|
Analog In |
Connector: Euroblock (Balanced) 3.81 mm Pitch
|
Minimum Input Level |
-70 dBu
|
Maximum Input Levels |
Microphone: +26 dBu
Line: +24 dBu Input Impedance: 2.2 kOhms or Higher |
Analog Output |
Connector: Euroblock (Balanced) 3.81 mm Pitch
|
Nominal Output Level |
+4dBu (When Ref.Level Set to Other Than -9 dBFS)
+6dBu (When Ref.Level Set to -9 dBFS) |
Maximum Output Level |
Switchable:
+15 dBu (Ref.Level: -9 dBFS) +18 dBu (Ref.Level: -14 dBFS) +20 dBu (Ref.Level: -16 dBFS) +22 dBu (Ref.Level: -18 dBFS) +24 dBu (Ref.Level: -20 dBFS) |
Output Impedance |
200 Ohms or Lower
|
RS-485 |
Connector: RJ-45
Cables: Category 5e or Faster STP Cables |
Ethernet |
Connector: RJ-45
Transmission Protocol: TCP/IP Ethernet Standard: 100BASE-TX Cables: Category 5e or Faster STP Cables |
Power |
AC 100 to 240 V, 50/60 Hz
|
Power Consumption |
21 W
|
Operating Temperature Range |
32 to 104°F / 0 to 40°C
|
Dimensions |
19.0 x 1.8 x 12.0" / 48.3 x 4.5 x 30.4 cm
|
Weight |
6.6 lb / 3.0 kg
|
