Spec
| Display |
None
|
| Channels of I/O |
Analog / Digital:
10 Input / 2 Output at 192 kHz |
| Maximum Sampling Rate |
192 kHz / 24-Bit
|
| Number of Microphone Preamps |
2 Preamps
|
| Input Level Adjustment |
2 x Knob
|
| Expansion Slots |
None
|
| Pad |
None
|
| High-Pass Filter |
None
|
| Solo/Mute |
None
|
| Analog Audio I/O |
2 x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line/Hi-Z Input
2 x 1/4" TRS Balanced Line Output 2 x 1/4" TRS Unbalanced Headphone Output |
| Phantom Power |
48 V (Selectable on Individual Inputs)
|
| Digital Audio I/O |
1 x TOSLINK Optical ADAT Input (S/MUX Support)
|
| Host Connection |
1 x USB-B
|
| Host Connection Protocol |
USB 2.0
|
| Sync I/O |
None
|
| MIDI I/O |
1 x DIN 5-Pin Input
1 x DIN 5-Pin Output |
| Sample Rates |
Up to 192 kHz
|
| Sample Rate Conversion |
None
|
| Bit Depths |
24-Bit
|
| Sync Sources |
None
|
| Clocking |
Internal:
<nbsp;> |
| Included Software |
None
|
| Included Plug-Ins |
None
|
| Power Requirements |
USB Bus Power
|
