main product photo
Loading...
AJA FS-MINI 3G-SDI UTILITY FRAME SYNC, SDI AND HDMI SIMULTANEOUS OUTPUTS

AJA FS-MINI 3G-SDI UTILITY FRAME SYNC, SDI AND HDMI SIMULTANEOUS OUTPUTS

AJA OG-X-FR OPENGEAR 2RU, 20-SLOT FRAME, SINGLE POWER SUPPLY

AJA OG-X-FR OPENGEAR 2RU, 20-SLOT FRAME, SINGLE POWER SUPPLY

32X32 COMPACT SDI ROUTER WITH 1 POWER SUPPLY

AJA
SKU
AJA-KUMO-3232
MFR#
KUMO-32X32-R2
$4,399.00
Availability: Out of stock

32X32 COMPACT SDI ROUTER WITH 1 POWER SUPPLY

Be the first to review this product
Add to Wish List:

SPECIAL SHIPPING RATES

On orders over $1000

WHOLESALING PRICING

Ask us how to become a Wholesaler

SECURED PAYMENT

Guaranteed safe payment options

The KUMO 3232 Compact SDI Router from AJA provides signal control and supports full broadcast specifications over 3G-SDI with quality that exceeds SMPTE specifications. This compact 2 RU format router is designed for broadcast, production, or postproduction environments including mobile sports trucks, edit suites, corporate video installations, or live theatrical A/V rigs.

Your Rating
Key Features
  • 32 x 3G-SDI Input
  • 32 x 3G-SDI Output
  • Mini-USB for IP Configuration
  • RJ45 Ethernet Port
  • RS-422 Serial Port
  • 2 RU

AJA KUMOSpecs

Video Format
270 Mb/s, 1.5 Gb/s, 3 Gb/s SDI
270 Mb/s DVB-ASI
Format agnostic, 125 Mb/s - 3 Gb/s
Video Input Digital
32 x 3G-SDI, BNC
SMPTE-259/292/424
Video Output Digital
32 x 3G-SDI, BNC non-inverting
SMPTE-259/292/424
Ancillary Data
Passes all SDI embedded ancillary data including audio
Cable Equalization
Belden 1694A:
3 Gb/s, up to 459.3' / 140 m
1.5 Gb/s, up to 656.2' / 200 m
270 Mb/s, up to 1312.3' / 400 m
Automatic operation
Reclocking
270 Mb/s, 1.483 Gb/s, 1,485 Gb/s, 2.966 Gb/s, 2.970 Gb/s - auto select
All other rates are passed through and not reclocked
Switching
Single, dual, and quad link modes
Switches in vertical blanking per SMPTE RP-168
Compatible Control Panels
AJA KUMO CP - 1 RU X-Y Ethernet control panel
AJA KUMO CP2 - 2 RU X-Y Ethernet control panel
Reference Input
2 x BNC, external
Looping, non-terminating
Blackburst or tri-level sync
Network Interface
1 x RJ45, 10/100/1000 Ethernet
Supports AJA KUMO Ethernet control panels, direct connect or networked
Grass Valley Native Protocol
Embedded web server for remote control
USB Interface
1 x mini-USB for IP configuration
Machine Control
1 x DB-9 female RS-422, grass valley native protocol
9-pin D-connector pinout: 1 GND, 2 TX-, 3 RX+, 4 GND, 5 No Connection, 6 GND, 7 TX+, 8 RX-, 9 GND, Shell GND
Power
10-14 VDC regulated, 18 W typical, 43.2 W max,
AC Adapter: 100-240 VAC, 50/60 Hz, universal input
Environment
Safe Operating Temperature: 32 to 104°F / 0 to 40°C
Safe Storage Temperature (Power OFF): -40 to 140°F / -40 to 60°C
Operating Relative Humidity: 10-90% noncondensing
Operating Altitude: up to 3000 m / 10,000'
Rack Space
2 RU
Dimensions
17.4 x 1.5 x 3.5" / 441.96 x 38.1 x 88.9 mm
Weight
4.6 lb / 2.1 kg
