AJA FIDO-T SINGLE CHANNEL 3G-SDI / OPTICAL FIBER TO LC FIBER MINI CONVERTER
SKU
AJA-FIDO-T
MFR#
FIDO-T-R0
$559.00
Availability:
Out of stock
AJA FIDO-T SINGLE CHANNEL 3G-SDI / OPTICAL FIBER TO LC FIBER MINI CONVERTER
Convert a 3G-SDI signal to an ST fiber output in resolutions up to 1080p. Transmit the output signal up to six miles at the max resolution over a single-mode fiber cable, and monitor the signal locally over a 3G-SDI loop output. AJA's FiDO-T-ST features one 3G-SDI input, one ST optical fiber output, and one 3G-SDI loop output, in a compact body suitable for indoor and outdoor use. Use it with compatible devices, or pair it with a corresponding FiDO Mini Converter.
Key Features
- SDI Input / ST Fiber Output / SDI Loop
- Up to 1080p Resolution
- Equalized and Reclocked Input
- ASI Compatible
- Meets All Relevant SMPTE Specifications
- Locking Power Connector
- 1.5W Power Consumption
- Includes 5-20V Worldwide Power Supply
- Suitable for Indoor and Outdoor Use
AJA T-STSpecs
| Formats |
3 Gbps, 1.5 Gbps, 270 Mbps (automatically selected based on input)
|
| Input |
1 x 3G/HD/SD-SDI on BNC
|
| Output |
1 x ST optical fiber
1 x 3G/HD/SD-SDI loop-out on BNC |
| Supported Resolution |
Up to 1920 x 1080p
|
| Power |
5-20 VDC
|
| Power Consumption |
1.5 W
|
| Dimensions |
4.6 x 1.7 x 0.9" (12 x 4.3 x 2.4 cm)
|
