BLACKMAGIC DESIGN BMD-CONVMBHS24K6G MINI CONVERTER - HDMI TO SDI 6G

BLACKMAGIC DESIGN BMD-CONVMBHS24K6G MINI CONVERTER - HDMI TO SDI 6G

BLACKMAGIC DESIGN MINI CONVERTER - AUDIO TO SDI VERSION 2

BLACKMAGIC DESIGN MINI CONVERTER - AUDIO TO SDI VERSION 2

BLACKMAGIC DESIGN MINI CONVERTER - SDI TO HDMI 6G

Black Magic Design
SKU
BMD-CONVMBSH4K6G
$199.00
Availability: In stock
BLACKMAGIC DESIGN MINI CONVERTER - SDI TO HDMI 6G
Be the first to review this product
Add to Wish List:

SPECIAL SHIPPING RATES

On orders over $1000

WHOLESALING PRICING

Ask us how to become a Wholesaler

SECURED PAYMENT

Guaranteed safe payment options

The Blackmagic Design SDI to HDMI 6G Mini Converter converts SDI in resolutions up to DCI 4K (4096 x 2160) at 24p and UHD 4K (3840 x 2160) up to 30p to HDMI. This is useful for connecting consumer devices that require HDMI signals with professional SDI video equipment. With a compact form factor and easy-to-use controls, the Mini Converter is ideal for a variety of broadcast, post production, and professional AV applications.

Using 4K HDMI and 6G-SDI technologies, the Mini Converter automatically detects the input video format and instantly changes between SD, HD, and UHD/DCI 4K formats. Featuring two SDI inputs, and both an SDI and HDMI output, the unit will automatically switch from the main SDI input to the alternate input if the main input fails. Audio is de-embedded from the SDI input and available in the HDMI output as well as the AES/EBU or analog audio output.

Your Rating

SDI to HDMI 6G Mini Converter Features

  • 2 x 4K SDI Input
  • 1 x HDMI Type A and 1 x SDI Output
  • Supports SD, HD, UHD 4K & DCI 4K Signals
  • Automatic Input Signal Detection
  • Analog & AES-EBU Digital Audio Outputs
  • De-Embeds Audio from SDI
  • Settings via Mini Switches or Software
  • USB 2.0 Port for Firmware Updates
  • 12V Universal Power Supply Included
  • 4:2:2 Sampling and color precision
  • HD scaler and SD down-conversion
  • 24-bit, 48 kHz audio sampling

General

Video Inputs 2 x BNC (6G-SDI)
Input Video Format SDI
DCI 4K at 23.98/24/25 fps
UHD 4K 23.98/24/25/29.97/30 fps
DCI 2K 23.98/24/25 fps
1080p 23.98/24/25/29.97/30/50/59.94/60 fps
1080PsF 23.98/24/25/29.97/30 fps
1080i 50/59.94/60 fps
720p 50/59.94/60 fps
Audio Inputs None
Video Outputs 1 x HDMI
1 x BNC (6G-SDI)
Output Video Format HDMI (4:4:4/4:2:2 RGB, YUV)
UHD 4K at 23.98/24/25/29.97/30 fps
1080p 23.98/24/25/50/59.94/60 fps
1080i 50/59.94/60 fps
720p 50/59.94/60 fps
576i / 625 lines
480i / 525 lines
Audio Outputs 2 x 1/4" TRS Stereo Analog Female
HDR Compatibility Not Specified by Manufacturer
Expansion Slots None
Wi-Fi None

Power

Power I/O 1 x Barrel (12 to 31 VDC) Input
Power Consumption Device: 12 to 18 VDC (5.2 W)

Environmental

Operating Temperature 32 to 72°F / 0 to 40°C
Storage Temperature -4 to 113°F / -20 to 45°C
Operating Humidity 0 to 90% (Non-Condensing)
