LIBEC LX7 HEAD WITH A PAN HANDLE /RT30B / BR-2B / FP-2B / RC-20

LIBEC LX7 HEAD WITH A PAN HANDLE /RT30B / BR-2B / FP-2B / RC-20

LIBEC ELECTRIC PEDESTAL WITH DOLLY FOR PTZ CAMERAS

LIBEC ELECTRIC PEDESTAL WITH DOLLY FOR PTZ CAMERAS

LIBEC ELECTRIC PEDESTAL WITH FLOOR SPREADER FOR PTZ CAMERAS

Libec
SKU
LIB-LX-EPED
MFR#
LX-ePed
was $3,150.00 Special Price $2,839.00
Availability: Out of stock
LIBEC Electric pedestal with Floor Spreader for PTZ cameras
Be the first to review this product
Add to Wish List:

SPECIAL SHIPPING RATES

On orders over $1000

WHOLESALING PRICING

Ask us how to become a Wholesaler

SECURED PAYMENT

Guaranteed safe payment options

Raise and lower your mounted camera of choice with this LX-ePed Electric Pedestal Column with Ground Spreader from Libec thanks to its handheld controller and working height range of 37.5 to 97.2". Mount a camcorder, PTZ, or other recording device on the tripod using the 1/4"-20 and 3/8"-16 screws on its 100mm ball head and 22 lb load capacity.

LAN ports on both the pedestal column and controller unit allow the devices to communicate with one another. The elevation rocker on the controller allows for the intuitive raising and lowering of the tripod's center column. The included ground spreader provides additional security to the system, and an AC/DC power adapter provides power.

Your Rating
Key Features
  • 2-Stage Electric Pedestal System
  • Controller with Elevation Rocker
  • 22 lb Load Capacity
  • 37.5 to 97.2" Height Range
  • Ground Spreader for Additional Stability
  • 100mm Bowl Head
  • 1/4"-20 and 3/8"-16 Camera Screws
  • LAN Control Cable, AC/DC Power Supply

Specs

Load Capacity
22 lb / 10 kg
Leg Sections
2
Minimum Height
37.5" / 95.3 cm
Maximum Height
97.2" / 247 cm
Bubble Level
Yes
Input and Output Connectors
1 x RJ45 LAN Control Input 1 x RJ45 LAN Control Output
1 x DC Barrel Power Input
Power Source
AC Adapter with Power Brick
AC Input Power
100 to 240 VAC, 50 / 60 Hz
Speed
14 to 40 Seconds
Run Time
3 Minutes (Continuous)
Environmental Protection
None
Operating Temperature
14 to 104°F / -10 to 40°C
Operating Humidity
90%
Mounting
1 x 1/4"-20 Screw
1 x 3/8"-16 Screw
2 x 1/4"-20 Thread
2 x 3/8"-16 Screw
1 x 100mm Bowl
Color
Black
Cable Length
98.4' / 30 m (LAN)
9.8' / 3 m (AC/DC Power)
Dimensions
39.6 x 9.5" / 1005 x 241 mm (Folded)
28 x 24.4" / 710 x 620 mm (Ground Spreader Width)
1.3' / 400 mm (Elevation)
5 x 1.6 x 1.4" / 128 x 40 x 36 mm (Controller)
Weight
24.7 lb / 11.2 kg (Excluding Controller and Power Adapter)
22.7 lb / 10.3 kg (Column Only)
