NEUMANN TLM-170R MULTI-PATTERN MIC WITH K 89 CAPSULE, FIVE REMOTE-CONTROLLABLE PATTERNS, WITH TILTING SIDE BRACKET
SKU
NEU-TLM-170R
was
$4,129.00
Special Price
$3,295.00
Availability:
In stock
NEUMANN TLM-170R MULTI-PATTERN MIC WITH K 89 CAPSULE, FIVE REMOTE-CONTROLLABLE PATTERNS, WITH TILTING SIDE BRACKET
The black TLM 170 R Large-Diaphragm Multipattern Condenser Microphone from Neumann is a large-diaphragm, multipattern condenser microphone and features FET 100 technology, a balanced, transformerless output stage, low self-noise, and an impressive dynamic range.
Specs
| Form Factor |
Large Diaphragm Mic / Stand/Boom Mount
|
| Capsule |
Condenser
|
| Polar Pattern |
Cardioid, Figure-8, Hypercardioid, Omnidirectional, Subcardioid/Wide Cardioid
|
| Frequency Range |
20 Hz to 20 kHz
|
| Maximum SPL |
144 dB SPL (.5% THD)
154 dB SPL (.5% THD, with Pad) |
| Form Factor |
Large Diaphragm Mic / Stand/Boom Mount
|
| Intended Sound Sources |
Vocals, Speech/Voice Over, Instrument, Orchestra
|
| Sound Field |
Mono
|
| Operating Principle |
Pressure Gradient
|
| Capsule |
Condenser
|
| Polar Pattern |
Cardioid, Figure-8, Hypercardioid, Omnidirectional, Subcardioid/Wide Cardioid
|
| Pattern Selection |
Switched (Adjustable on Mic)
|
| Tone Adjustment |
None
|
| Gain Adjustment |
None
|
| Indicators |
None
|
| Windscreen |
None
|
| Frequency Range |
20 Hz to 20 kHz
|
| Maximum SPL |
144 dB SPL (.5% THD)
154 dB SPL (.5% THD, with Pad) |
| Impedance |
50 Ohms
|
| Load Impedance |
1000 Ohms (Rated)
|
| Sensitivity |
8 mV/Pa at 1 kHz into 1 Kilohm
|
| Output Level |
10 dBu (Max)
|
| Dynamic Range |
130 dB
|
| Signal-to-Noise Ratio |
80 dB A-Weighted
68 dB CCIR |
| Equivalent Noise Level |
14 dB A-Weighted
26 dB CCIR |
