INOVONICS 660 INOMINI DAB+ BROADCAST MONITOR | RECEIVER: ADJUSTABLE L/R ANALOG & AES OUTPUTS | ALARMS |
SKU
INO-660
MFR#
660
was
$460.00
Special Price
$414.00
Availability:
Out of stock
The 660 DAB/DAB+ Confidence Monitor provides off-air reception of all standard DAB & DAB+ broadcasts in a compact INOmini package.
The extremely sensitive and selective front end of the AARON 640 digitally decodes the entire Analog baseband. Outputs are low-latency MPX, Balanced Analog and AES-Digital signals for retransmission.
The back panel provides a 50 Ohm (N) antenna connector, a true (off air) composite outputs, Balanced Analog and AES-Digital audio, and remote IP access. Rear-panel and self-logging alarms constantly check for Audio Loss, RF Loss, and RDS Loss (or ‘hijacking’). Online notifications can alert personnel with e-mail or instant text messages when any of the alarms occur. The front panel displays left and right audio metering, local LED alarms and an LCD screen with jog wheel for advanced control and editing of all tuning and monitoring parameters.
AARON 640's "responsive" web interface allows complete setup, listening, logging and control of the unit from your PC, tablet or smartphone, and reliable 2-way connectivity is ensured with a built-in Dynamic DNS utility. Advanced off-air metering tools include an FM BandScanner and FFT of the MPX region. Reception bandwidth, auto-blending and many other receiver parameters are controlled via manual or automatic reception processing.
Features:
- Reception of all standard DAB and DAB+ broadcasts
- Easy setup using the LCD screen and jog-wheel navigation of the receiver’s menu tree
- Front-panel display of most-essential DAB and DAB+ PAD (Program-Associated Data) information
- Analog L/R and AES-digital program line outputs
- Front-panel alarms with rear-panel tallies for Carrier Loss, Digital Program Loss and Audio Loss
- Firmware updates via USB port on front panel
- Headphone jack
Specifications:
Tuning Range
- DAB Band III, Mode I (174.928MHz - 239.200MHz); all EBU-sanctioned frequency allocations (Blocks 5-12, A-D) plus Block 13 A-F
Receiver Sensitivity
- 10μV for error-free reception
Antenna Input
- 75-ohm (BNC)
Audio Codecs
- MPEG-1 Audio Layer 2 (MP2); HE-AAC (AAC+)
Audio Response
- ±0.25dB, 20Hz-20kHz
Signal Parameters Displayed
- FQ (FIC Quality), RF (RSSI), SNR, CNR
Metadata Displayed
- Ensemble Label, Component List & ID, Service List & ID, Dynamic Label, PTY, Sample Rate, Bit Rate, Gain, Mode, Service Mode, Protection Info, Current CU & Address, Country, Language, Time & Date
Analog Audio Outputs
- Balanced Analog L/R (XLR); level is menu-adjustable between –15dBu and +15dBu. S/N: 100dbA @ 3kHz for Analog output.
Digital Audio Output
- AES3 (XLR), 44.1kHz sampling rate; audio level is menu-adjustable between –30dBFS and 0dBFS. S/N: >100dbA @ 3kHz for AES Digital.
Headphone Jack
- 3.5mm TRS with menu-adjustable level
USB Connector
- Allows firmware updates
Alarm Tallies
- Individual open-collector NPN transistor outputs for Low Signal, DAB Loss, Audio Loss; alarm thresholds, delays and logic polarity
Power Requirement
- +12VDC at 220mA (2.1mm x 5.5mm coaxial; A universal inline switchmode power supply is provided.
Mounting Options
- An optional rack adapter accepts up to three INOmini modules in a 1U rack space.
Size and Weight
- 1.6”H x 5.5”W x 5.5”D
- 4 lbs shipping weight
Environmental
- Continuous operation at ambient temperatures between 32ºF/0ºC and 122ºF/50ºC; 0-95% relative humidity, non-condensing, altitudes to 10,000ft/3,048m
