RVR TEX1002/TLW COMPACT 1 KW SOLID STATE MIC- CONTROLLED FM MONO/MPX/STEREO EXCITER -TRANSMITTER,
SKU
TEX1002LCD/TLW
MFR#
TEX1002LCD/S-TLW
was
$7,917.00
Special Price
$5,900.00
Availability:
Out of stock
RVR TEX1002/TLW COMPACT 1 KW SOLID STATE MIC- CONTROLLED FM MONO/MPX/STEREO EXCITER -TRANSMITTER,
High quality modern transmitter at an extremely low price, compact, non-deformable and light because it is made of stainless steel chassis. It guarantees high continuity of operation in any working condition through an automatic control (ALC) and a Foldback protection with adjustable output power from 10 to 100%.
It has standard L&R, Mono, MPX and SCA / RDS analogue audio inputs, with the possibility of TOSLINK and optional AES / EBU as well as the integrated RDS encoder (UECP standard Low distortion values, a high signal-to-noise ratio, combined with saving of energy and environmental resources of high yields (over 70% on the whole band) ensures an excellent transmission service.
Limited maintenance is facilitated by extreme accessibility, resulting from an advanced modular engineering, and by a water-washable air filter. A complete control based on ARM microprocessor, from interactive menus on TFT Touch display of all the main parameters and an integrated WEB / SNMP telemetry system (optionally) guarantee full compliance with EC, FCC and CCIR regulations.
Features:
- New Generation FM Transmitters with 4.3" TFT color
- graphic touch screen.
- Last generation planar RF Pallet with LD-MOSFET
- Enhanced cooling with open-cell polymeric air filter.
- Temperature controlled cooling system.
- High efficiency Heatsink.
- New patended power supply for better performances.
- Effective RF Output Filter for maximum
- spectral cleaness.
- Audio Setting directly from Menu.
- Built-in RTC Timer for automatic change of
- the output power.
- Re-engineered air cooling system.
- Full compliance with CCIR, EN,
- Standard FM Frequency: 87.5 - 108 MHz.
- Output Power continuously adjutable from 10 to 100%
- Low distortion and intermodulation values.
- APC Automatic Power Control for maximum stability of th output Power.
- Energy saving PFC Power Supply for maximum of efficiency.
- Inputs: Analogue Stereo L&R, Mono, MPX.
- Two auxilliary Inputs for external RDS/SCA.
- Upgradable with integrated RDS Encoder
- WEB, SNMP2, Serial remote controls.
Specifications:
| Parameter | U.M. | Value | Notes | |
| GENERALS | ||||
| Frequency range | MHz | 87,5 ÷ 108 | ||
| Rated output power | W | 1000 | Continuously adjustable from 10 to 100% | |
| Modulation type | F300E | |||
| Operational mode | Mono, Stereo, MPX | |||
| Working temperature | °C | -5 to +50 | ||
| Working humidity | % | 95 | Without condensing | |
| Working altitude | mt | Up to 3000 * | * With adequate air evacuation system in site | |
| Frequency setting | kHz | 10 | Steps | |
| Frequency stability | Temperature range from -5°C to 50°C | ppm | ±1 | |
| Modulation capability | Refered @ 0dBu for 75kHz | kHz | 150 | Meets or exceeds all FCC and CCIR rules |
| Pre-emphasis | μS | 0 50, 75 | Selectable | |
| POWER REQUIREMENTS | ||||
| AC Power input | AC Supply Voltage | VAC | 230 ±15% | |
| AC Apparent Power Consumption | VA | 1450 | ||
| Active Power Consumption | W | 1447 | ||
| Power Factor | 0,998 | |||
| Overall Efficiency | % | Typical 70 * | * Up to 72 in specific conditions | |
| Connector | VDE 16A | |||
| MECHANICAL DIMENSIONS | ||||
| Phisical dimensions | Front panel width | mm / inch | 483 / 19 | EIA rack |
| Front panel height | mm / inch | 88 / 3 1/2 | 2HE | |
| Overall depth | mm | 561 | ||
| Chassis depth | mm | 470 | ||
| Weight | kg | Approx. 12 | ||
| Cooling | Forced, with internal fan | |||
| Acoustic noise | dBA | < 75 | ||
| AUDIO INPUTS | ||||
| Left/Mono | Connector | XLR F | ||
| Type | Balanced | |||
| Impedance | Ohm | 10 or 600 k | ||
| Input Level / Adjust | dBu | -12 to +12 | Continuosly adjustable | |
| Right | Connector | XLR F | ||
| Type | Balanced | |||
| Impedance | Ohm | 10 or 600 k | ||
| Input Level / Adjust | dBu | -12 to +12 | Continuosly adjustable | |
| MPX | Connector | BNC | ||
| Type | Unbalanced | |||
| Impedance | Ohm | 10 k | ||
| Input Level / Adjust | dBu | -12 to +12 | For 7,5 KHz FM, adjustable | |
| SCA/RDS | Connector | 2 x BNC | ||
| Type | Unbalanced | |||
| Impedance | Ohm | 10 k | ||
| Subcarier Level @ 0 dBu | dB | -17 to -40 | For 7,5 KHz FM, adjustable | |
| AES/EBU (OPTIONAL) | Connector | XLR F | ||
| Type | Balanced | |||
| Impedance | Ohm | 110 | ||
| Input Level / Adjust | dBfs | 0 to -10 | For 7,5 KHz FM, adjustable | |
| TOSLINK (OPTIONAL) | Connector | TOSLINK | ||
| Type | Optical | |||
| OUTPUTS | ||||
| RF Output | Connector | 7/8” | ||
| Impedance | Ohm | 50 | ||
| RF Monitor | Connector | BNC | ||
| Impedance | Ohm | 50 | ||
| Output Level | dBm | 0 ± 4 | ||
| Pilot output | Connector | BNC | ||
| Load Impedance | Ohm | >5 k | ||
| Output Level | Vpp | 1 | Sinusoidal | |
| FUSES | ||||
| On mains | 2 External fuse F 16 A - 6x30 mm | |||
| On services | X | |||
| On PA Supply | X | |||
| On driver supply | X |
