main product photo
Loading...
BROADCAST DEVICES ATB-300-1 AUDIO TOOLBOX AES SYNCHRONOUS AUDIO SWITCHER WITH INTEGRATED SILENCE SENSOR 4/0 AES INPUTS X 0/4 AES OUTPUTS

BROADCAST DEVICES ATB-300-1 AUDIO TOOLBOX AES SYNCHRONOUS AUDIO SWITCHER WITH INTEGRATED SILENCE SENSOR 4/0 AES INPUTS X 0/4 AES OUTPUTS

BROADCAST DEVICES ATB-300-2 AUDIO TOOLBOX AES SYNCHRONOUS AUDIO SWITCHER WITH INTEGRATED SILENCE SENSOR 4 AES I//O , 4 ANALOG L/R BALANCED INPUT

BROADCAST DEVICES ATB-300-2 AUDIO TOOLBOX AES SYNCHRONOUS AUDIO SWITCHER WITH INTEGRATED SILENCE SENSOR 4 AES I//O , 4 ANALOG L/R BALANCED INPUT

BDI CDS-302 COMPOSITE FM STEREO SWITCHER/DA/SILENCE SENSOR

BDI
SKU
BDI-CDS-302
MFR#
CDS-302
$1,495.00
Availability: Out of stock
BDI CDS-302 COMPOSITE FM STEREO SWITCHER/DA/SILENCE SENSOR
Be the first to review this product
Add to Wish List:

SPECIAL SHIPPING RATES

On orders over $1000

WHOLESALING PRICING

Ask us how to become a Wholesaler

SECURED PAYMENT

Guaranteed safe payment options

The CDS-302 Automatic Composite Audio Switcher/DA is still the best base band FM stereo management product available. The unit accepts 2 base band inputs and distributes the selected input to 3 base band outputs. The unit incorporates our exclusive RBDS loop through feature for RBDS lock and distribution using only one RBDS generator. The automatic feature allows for silence detected switchover in the event of an STL failure or processor lockup.

Your Rating

Features:

  • Accepts 2 Composite Baseband FM Stereo balanced or unbalanced Inputs
  • D.C. Coupled Signal Path for transparent handling of baseband signals
  • RBDS Loop through - keeps RBDS locked and added to either composite input
  • 3 Output Distribution Amplifier with individual level controls
  • Automatically switches between inputs upon silence - user adjustable 30 or 60 seconds
  • Accepts optional BDI model CTD-1 module to provide decoded AES3 or analog replica of incoming baseband - See block diagram on page 2
  • 19" single R.U. chassis with integrated 120/240 VAC power supply

Specifications:

Feature Specification
Inputs 2 x BNC (Balanced or Unbalanced), 10K or 50 Ohms
Outputs 3 x Balanced 50 Ohm BNC (2 Rear, 1 Front Panel)
Maximum Output Level 4 V PP into 50 Ohms10 V PP into Bridging 10K Load
Frequency Response ±0.07 dB (1 Hz – 53 kHz)±0.1 dB (53 – 100 kHz)
Total Harmonic Distortion 0.05% or Less at 1 kHz, 4 V PP into 50 Ohms
IMD Distortion 0.05% or Less (SMPTE 4:1 Method)
Remote Control/Status DB9F Connector: Momentary Input Select, Error Reset, NC/C/NO Dry Status for Channel and Error
Silence Sensor User Defined: 30 or 60 Seconds
Power Requirements 100–240 VAC, 50–60 Hz @ 0.25 AIEC Power Entry Cord
Dimensions 19" W x 8.25" D x 1.75" HStandard EIA Rack Enclosure Mount
Operating Temperature Range 0–55 °C (Non-Condensing Atmosphere)
Carton Dimensions / Weight 22" L x 14" W x 7" H7 lbs.
