Specs
Display |
None
|
Channels of I/O |
Analog:
4 Inputs / 4 Outputs |
Maximum Sampling Rate |
192 kHz / 24-Bit
|
Number of Microphone Preamps |
4 Preamps
|
Input Level Adjustment |
4 x Knob
|
Expansion Slots |
None
|
Pad |
None
|
Gain/Trim Range |
Mic/Line/Hi-Z Inputs:
56 dB |
High-Pass Filter |
None
|
Solo/Mute |
None
|
Analog Audio I/O |
4 x XLR 3-Pin Balanced Mic Input (Front Panel)
2 x 1/4" TRS Balanced/Unbalanced Line/Hi-Z Input (Front Panel) 2 x 1/4" TRS Balanced Line Input (Front Panel) 4 x 1/4" TRS Balanced Line Output 2 x 1/4" TRS Unbalanced Headphone Output (Front Panel) |
Phantom Power |
48 V, Selectable On/Off (Applied to All Inputs)
|
Digital Audio I/O |
None
|
Host Connection |
1 x USB-C
|
Host Connection Protocol |
USB 2.0
|
USB (Non-Host) |
None
|
Sync I/O |
None
|
Network I/O |
None
|
MIDI I/O |
1 x DIN 5-Pin Input
1 x DIN 5-Pin Output |
Frequency Response |
Mic, Line Inputs:
20 Hz to 20 kHz +0/-0.4 dB (at 44.1/48 kHz, JEITA) 20 Hz to 40 kHz +0/-0.4 dB (at 88.2/96 kHz, JEITA) Line Outputs: 20 Hz to 20 kHz +0.2/-0.1 dB (at 44.1/48 kHz, JEITA) 20 Hz to 40 kHz +0.2/-0.4 dB (at 88.2/96 kHz, JEITA) |
Maximum Input Level |
Mic Inputs:
+9 dBu Line Inputs: +20 dBu Hi-Z Inputs: +10 dBV |
Maximum Output Level |
Line Outputs:
+20 dBu |
Headphone Output Power |
45 mW per Channel into 32 Ohms (0.1% THD)
|
Impedance |
Mic Inputs:
2.2 Kilohms Line Inputs: 10 Kilohms Hi-Z Inputs: ≥ 1 Megohm Line Outputs: 210 Ohms |
SNR |
Mic Inputs:
110 dB (A-Weighted, Min Gain) Line Inputs: 108 dB (A-Weighted, Min Gain) Line Outputs: 110 dB (A-Weighted, Max Gain) |
THD+N |
Mic Inputs:
0.0013% (1 kHz, Min Gain) Line Inputs: 0.0011% (1 kHz, Min Gain) Line Outputs: 0.0012% (1 kHz) |
EIN |
-128 dBu
|
OS Compatibility |
macOS 10.13
macOS 11 or Later Windows 7 or Later iPadOS 13 or Later iOS 11 or Later *As of November, 2021: Check with manufacturer for the most up-to-date compatibility |
Included Software |
Cubase LE
|
Compatible Software (Not Included) |
Any Core Audio (Mac) Compliant Software
|
Included Plug-Ins |
Virtual Instruments:
SampleTank SE |
Supported Drivers/API & Plug-Ins |
Core Audio (Mac)
ASIO WDM |
Processor Requirement |
2 GHz or Better
|
RAM Requirements |
2 GB
|
Mobile Device Compatibility |
iPad
iPhone |
Required Hardware |
Available USB 2.0 Port
USB Cable (Included) |
Internet Connection |
Required for Registration, Software/Driver Download
|
Power Requirements |
AC/DC Power Adapter (Not Included) or USB Bus Power
|
AC/DC Power Adapter |
12 VDC, Center-Positive (Included)
|
Power Consumption |
2.25 W
|
Operating Temperature |
41 to 95°F / 5 to 35°C
|
Dimensions |
11.7 x 6.3 x 2.6" / 29.6 x 16 x 6.5 cm (Including Controls and Protrusions)
|
Weight |
3.5 lb / 1.6 kg
|
