Product Specs
Mic Input | |
Frequency Response | 20 Hz - 20 kHz +/- 1,5 dB @ 44.1 + 48 kHz |
Input refered noise | -105 dB (@60dB Gain) |
THD+N | 0,01% @ 20 dB GainTHD+N |
Gain | Up to 60dB gain |
High Pass Filter | 12 dB/oct. @ 80, 100, 120, 150, 180, 200 Hz (switchable) |
Capsule Filter | 3 times parametric filters autoselected by capsule type recognition |
Line Input | |
Line Input Level Balanced | -20 dBu …. 6 dBu @FS |
Line Input Level Unbalanced | -20 dBu …. 0 dBu @FS |
THD+N | 0,01% or -78 dB @ -3 dBFS |
Line Output | |
Line Output Level Balanced | -20 dBu …. 6 dBu @FS |
Line Output Level Unbalanced | -20 dBu …. 0 dBu @FS |
Line Output Frequency Response | 20Hz - 20kHz +/- 1dB @44.1 and 48Hu |
THD+N | 0,01% or -78 dB @ -3 dBFS |
Digital Parameters | |
Sampling Frequency | 48 kHz, 44.1 kHz, 32 kHz |
Bit Resolution | 16 Bit |
Audio Formats | Linear PCM, MPEG 1 Layer 2 |
Bit rates MPEG mono | 128, 160, 192kbps |
Bit rates MPEG dual channel | 256, 320, 384 kbps |
Number of channels | 1 mono or 2 dual channel (mono) |
Headphone Out | |
Minimum Impedance | 16 Ohm |
Output Power | 40 mW @ 16 Ohm |
Memory | |
Memory Card | SD or SDHC Memory Card up to 16GB |
File System | FAT16 FAT32 (SD-CARD) |
File Format | BWF, WAV, MP2, Support of BWF Header information (Version 0) |
Data Connection | USB 2.0 |
Recording Time | Recording time depends on SD Card and File-Format: 2GB = 22.75hrs @192kBps mono |
Dimensions Recorder | Length: 193mm O : 38mm |
Weight | 283g |
