main product photo
Loading...
CLEAR-COM RS 703 ENCORE TW BELTPACK TWO CHANNEL , WITH PROGRAM AUDIO 0525

CLEAR-COM RS 703 ENCORE TW BELTPACK TWO CHANNEL , WITH PROGRAM AUDIO 0525

CLEAR-COM U-BOX-X3 ENCORE SURFACE MOUNT: 1 CH, DESK/WALL FOR KB SPEAKER STATIONS 0525

CLEAR-COM U-BOX-X3 ENCORE SURFACE MOUNT: 1 CH, DESK/WALL FOR KB SPEAKER STATIONS 0525

CLEAR-COM KB-701 ENCORE SPEAKER STATION: 1CH FLUSH MOUNT WITH SPEAKER, PROGRAM AUDIO. FLUSHED MOUNTED MICROPHONE 0525

CLEARCOM
SKU
CLE-KB-701
MFR#
KB-701
$675.00
Availability: Out of stock
CLEAR-COM KB-701 ENCORE SPEAKER STATION: 1CH FLUSH MOUNT WITH SPEAKER, PROGRAM AUDIO. FLUSHED MOUNTED MICROPHONE 0525
Be the first to review this product
Add to Wish List:

SPECIAL SHIPPING RATES

On orders over $1000

WHOLESALING PRICING

Ask us how to become a Wholesaler

SECURED PAYMENT

Guaranteed safe payment options

The Clear-Com KB-701 is a single-channel remote speaker station with half-duplex, push-to-talk operation and a built-in speaker. This flush-mountable unit includes four internally programmable modes of operation with microprocessor-controlled logic and switching. You also get a balanced local program input with separate level control and visual and audible call signaling. At Sweetwater, we appreciate the KB-701's flexibility. It includes an optional 4-wire daughterboard, it can be mounted on a wall or a console, or it can be installed into a V-Box for portable or desktop use. If you're searching for a high-quality analog partyline intercom system, you can't go wrong with the KB-701.

Your Rating

Features:

  • Half-duplex, push-to-talk functionality
  • Four modes of operation that are internally programmable
  • Microprocessor controlled logic and switching
  • Balanced local program input with separate level control
  • Visual and audible call signaling
  • Optional 4-wire daughter board for flexibility
  • Wall or console mountable, or optional V-Box for portable or desktop use
  • Built-in speaker

Specifications:

Program Line Input
Max Level Before Clipping ≥ 20 dBu
Input Impedance ≥ 5 kΩ
Speaker Output
Load Impedance ≥ 4 Ω
Max Output Level Before 1% Distortion 20 dBu ± 2 dBu
Partyline Output
Noise < -74 dBu
Output Impedance > 10 kΩ
Partyline Input
Crosstalk < -60 dB
Max Level Before Clipping ≥ 12 dBu
Frequency Response
Program Input – Speaker Out 200 – 18 kHz ± 3 dB
Partyline – Speaker Out 200 – 18 kHz ± 3 dB
Maximum Distortion
Program Input – Speaker Out ≤ 0.5%
Partyline – Speaker Out ≤ 0.5%
Noise
Program Input – Speaker Out < -60 dBu
Partyline – Speaker Out < -50 dBu
Maximum Gain
Program Input – Speaker Out ≥ 24 dB
Partyline – Speaker Out ≥ 40 dB
Power Requirements
Input Voltage Range 20 – 30 V DC
Input Current (Idle) ≤ 90 mA
Input Current (Max) ≤ 110 mA
Internal Connectors and Jumpers
Intercom Line Five Terminal Connector
Program Input Three Terminal Connector
Option Switches Three DIP Switches
Environmental 32° – 122°F (0° – 50°C)
Dimensions 4.5 x 8.5 x 1.75 in (H x W x D) / 114 x 210 x 44 mm
Weight 1.04 lbs (0.47 kg)
