main product photo
Loading...
BURK PLUS-X600 ETHERNET I/O INTERFACE FOR ARC PLUS PROVIDES (16) INPUTS,

BURK PLUS-X600 ETHERNET I/O INTERFACE FOR ARC PLUS PROVIDES (16) INPUTS,

BURK PLUS-X ICRU CONNECTS 8 PAIRS OF COMMAND RELAYS TO THE ARC PLUS OVER THE LAN AT THE SITE. USES S

BURK PLUS-X ICRU CONNECTS 8 PAIRS OF COMMAND RELAYS TO THE ARC PLUS OVER THE LAN AT THE SITE. USES S

BURK PLUS-X GSC CONNECTS TWO EXISTING GSC/VRC WIRING INTERFACE PANELS

Burk
SKU
BUR-PLUS-X-GSC
MFR#
PLUS-X-GSC
$2,265.00
Availability: Out of stock
BURK PLUS-X GSC CONNECTS TWO EXISTING GSC/VRC WIRING INTERFACE PANELS
Be the first to review this product
Add to Wish List:

SPECIAL SHIPPING RATES

On orders over $1000

WHOLESALING PRICING

Ask us how to become a Wholesaler

SECURED PAYMENT

Guaranteed safe payment options

Streamline Your System Upgrade
Introducing the Plus-X GSC Adapter, the ultimate solution for upgrading your legacy GSC and VRC systems efficiently and affordably. This innovative adapter allows for a seamless transition to the ARC Plus Touch by connecting up to two GSC/VRC wiring interfaces and command relays using the existing DB37 cables. With the Plus-X GSC Adapter, not a single channel requires rewiring, saving countless hours and significantly reducing upgrade efforts.

Cost-Effective System Enhancement
Upgrading your system doesn't have to break the bank. The Plus-X GSC Adapter is designed to be a cost-effective solution, providing all the necessary I/O for up to 16 channels without the need for additional input and output units. This adapter is the key to unlocking the full potential of your system with minimal investment.

Your Rating

Features:

  • Seamless Connection for Two Wiring Interfaces and Two Command Relays
  • Direct ARC Plus Access to Existing GSC/VRC Channels Without Rewiring
  • Ethernet Link to ARC Plus for Enhanced Communication and Control

Specifications:

Dimensions 1.75" (4.45 cm) H x 19" (48.26 cm) W x 12" (30.48 cm) D
Operating Temperature 0° to 40° C
Power Requirements 100 to 240VAC, 47–63Hz, 1A
Power entry module with standard, grounded power cord supplied
1A fuse protection
Connectivity Ethernet connection to ARC Plus
DB37 cables to Command Relay and Wiring Interface (not included)
Channel Capacity 16 metering, 16 status, and 16 command channels
Status channels are software-selectable as pull-up or pull-down
Metering Input Range -10VDC to +10VDC
Metering Input Accuracy > 99.75% accuracy, full scale
Status Input Range > 0 to +28VDC or switch closure
Output Types 32 open collector outputs (16 raise, 16 lower)
Maximum 250mA, 28V
