main product photo
Loading...
COAXIAL DYNAMICS 86750-1 50 KW DUMMY LOAD FORCED AIR COOLED 3-1/8

COAXIAL DYNAMICS 86750-1 50 KW DUMMY LOAD FORCED AIR COOLED 3-1/8 " EIA FLANGE

STACO AVR-20WCSY075 75KVA/208 AMP 3 PHASES 208/120 I/O 60 HZ AUTOMATIC VOLTAGE REGULATOR SYSTEM 1025

STACO AVR-20WCSY075 75KVA/208 AMP 3 PHASES 208/120 I/O 60 HZ AUTOMATIC VOLTAGE REGULATOR SYSTEM 1025

RVR FTCSDC20 3 CHANNEL COMBINER STARPOINT 20+20+20 KW DOUBLE CAVITY

RVR
SKU
FTCSDC20
MFR#
FTCSDC20
$38,503.30
Availability: Out of stock
RVR FTCSDC20 3 CHANNEL COMBINER STARPOINT 20+20+20 KW DOUBLE CAVITY
Be the first to review this product
Add to Wish List:

SPECIAL SHIPPING RATES

On orders over $1000

WHOLESALING PRICING

Ask us how to become a Wholesaler

SECURED PAYMENT

Guaranteed safe payment options

The star combiner basically consist of parallel connecting several transmitters to a single antenna system through suitable band pass filters, each on tuned transmitter frequency to which it's connected.

Your Rating

Features:

  • 3 CHANNELS COMBINER
  • IMPEDANCE 50 Ohm
  • FM BAND 87.5+108 MHz
  • BAND II
  • STARPOINT TYPE
  • Distortion — Free Transmission
  • Star-Point System with double band-pass cavity filters
  • Low Loss, High Isolation
  • Natural Convection

Specifications:

Model FTCSDC20
Impedance 50 Ohm
Frequency Range 87.5 – 108 MHz
VSWR ±150 KHz 1.1:1 max
Insertion Loss At fo: 0.1 – 0.15 dB max
Return Loss ±150 KHz -26 dB
Isolation ±1.2 MHz ≥ 30 dB
Number of Inputs 3
Number of Outputs 1
Connectors Input: 3-1/8" Output: 4-1/2"
Maximum Power 20 kW per Channel
Working Temperature -20°C to +50°C
Colour Enamel Gray (RAL 7001)
Materials Aluminium, Brass, Copper, PTFE, Stainless Steel, Silver-plated (≥12 g)
