360 SYSTEMS TSS-4000 4 CHANNEL HD/SD SERVER ( 4 PLAYOUT ONLY ) 4 TB STORAGE WITH REMOTE WORKSTATION.
SKU
360-TSS-4000
MFR#
TSS-4000
$25,995.00
Availability:
Out of stock
360 SYSTEMS TSS-4000 4 CHANNEL HD/SD SERVER ( 4 PLAYOUT ONLY ) 4 TB STORAGE WITH REMOTE WORKSTATION.
More channels for the same price* = lower cost per channel. For those customers requiring high playout channel counts, the TSS-4000 provides exceptional cost per channel. The TSS-4000 is a compact 1U server with up to 8TB of storage and offers 4 simultaneous HD or SD playout channels. With the same software and the core reliability of the TSS line of server, the TSS-4000 is the choice for broadcast quality playout.
Features:
- 4 Playout Channels
- 16 Channels Embedded Audio
- H.264 and MPEG2 Encoding / Decoding
- Automatic Up/Down/Cross Conversion of HD or SD content
- Remote Control From PC’s via Ethernet
- Redundant Power / Cooling
- 1U Form Factor
Specifications:
Video
- Record and play in 720p, 1080i or SD on any channel
- Various standard codec and file formats are accepted for playout, such as H.264 or MPEG-2 in .mxf, .mp4, .mpg or .mov containers.
- Independently configure each output to broadcast in 720p, 1080i or SD
- Perform jog and shuttle for rapid movement within a clip
- Smooth slow motion playout
- 16 channels of embedded audio per video channel
- Configurable for 29.97/59.94 or 25/50
- High quality 10 bit video and 24 bit audio support
Reliability
- Redundant cooling and power
- Redundant RAID 5 storage
- Linux based operating system
Connectivity
- HD-SDI, SD-SDI compatibility
- Gigabit Ethernet
- Serial port control for each channel via the VDCP or Odetics protocols for use with automation or remote controls
- Independent GPI inputs and outputs (12 each) for external triggering or control
Software
- Automatic conversion plays SD and HD files back-to-back
- Local software GUI
- Remote control from a PC
- Record & playlisting
- 4 Channels, 4 Record or Playout
- 1U, Chassis Form Factor
- 16 Channels Embedded Audio
- H.264 and MPEG2 Encoding / Decoding
- Automatic Up/Down/Cross Conversion of HD or SD content
- Remote Control From PC’s via Ethernet
- Redundant Power / Cooling
VIDEO
- Video Input 4 Channels
- Video Outputs 4 Channels
- Simultaneous video streams 4 total in any configuration of record or playout
- HD Input/Output HD-SDI (SMPTE 292M), SD-SDI (SMPTE 259M)
- Video Format 1080i at 29.97 or 25 Hz; 720p at 59.94 or 50 fps; 525/60 NTSC; 625/50 PAL
- Encoding Format H.264 or MPEG2
- HS/SD Scaling Up, Down, and Cross Conversion of Any File Format to Selected Output
- Jog/Shuttle Zero to 128X, forward/reverse
- Slow Motion Play with audio Zero to +/- 2X, forward/reverse
- Frame Accuracy Frame accurate play, pause and stop
- Genlock Input Blackburst or tri-level
ANCILLARY DATA
- Ancillary Data HD – 608/708 in VANC; SD – Line 21 VBI
- AUDIO INPUTS / OUTPUTS (per video channel)
- SDI Embedded Audio 16 channels
- STORAGE
- Disk Storage System SATA array, four – 1 or 2 Terabyte drives, Hardware RAID 5 controller
- Total Capacity 8 Terabytes (4 Terabytes standard model)
- Drive Replacement Hot Swappable, removable from behind front panel
CONNECTIVITY
- Networking Gigabit Ethernet
- Serial Control VDCP or Odetics protocols, 9-pin on CXP-5 module (optional).
- GPI Control 12 Inputs, Outputs, Programmable on CXP-5 module (optional)
MISCELLANEOUS
- Fault Monitoring LEDs Front Panel LEDs, power, system, network
- Fault Monitoring Output GPI output, open collector
- Software Updates USB
- Power Supply Dual Redundant, 100-250V – 50/60 Hz. 750W, rear panel plug-in
- Cooling Redundant fans
- Chassis 1-RU x 19” Rack, Weight: approx 45 lb. (22 kg)
